GA-SERIES GENERAL GRAVURE INK FOR PLASTIC LAMINATED FILM

GA-series general gravure ink for plastic laminated film is an alcohol-ester soluble made of polyurethane as its main resin, which is typically applicable to gravure printing on BOPP, PET and NY film.

I. Scope of Application

1. Applicable film:

BOPP film with surface tension≥ 38dyn;PET film with surface tension≥ 50dyn;NY film with surface tension≥ 52dyn;Printing grade K coating film (including K cellophane);Printing grade PT cellophane film.

2. Applicable lamination process:

Suitable for the process of dry lamination, solvent-free lamination and PE-extrusion lamination; while not suitable for PP-extrusion lamination process.

Ⅱ. Application Characteristics

1. Excellent printability, suitable for all kinds of gravure printing from low speed to high speed;

2. The printing residual solvents are extremely low, in line with environmental protection, safety, non-toxic and hygienic requirements.

Ⅲ. Standard Color Notation

GA1002  Red          GA1143  Golden Red    GA1201  Scarlet      GA1891  Peach

GA2003  Yellow       GA2017  Orange        GA3002  Blue        GA4003  White

GA5002  Black        GA6050  Green         GA7045  Purple       GA8002  Varnish

Ⅳ. Printing Viscosity

Printing speed		Above 200m/min	100-200m/min	Below 100m/min
Printing Viscosity / Zahn Cup #3	Colors	13±1s	13.5±1s	14±1s
	White	12.5±1s	13±1s	13.5±1s

Ⅴ. Dilution Solvent Ratio

1. The dilution solvent reference ratio for white ink

Type	Ethyl acetate	N-propyl acetate	Isopropyl alcohol
Quick-drying	70	20	10
Normal-drying	50	40	10

Slow-drying

20

70

10

2. The dilution solvent reference ratio for color ink

Type	Ethyl acetate	N-propyl acetate	N-butyl acetate	Isopropyl alcohol
Quick-drying	20	60	—	20
normal-drying	—	80	—	20
Slow-drying	—	40	40	20

Ⅵ. Notice

1. In practical application, the performance of ink would be affected by the environmental temperature and humidity, printing facility and process, as well as plate making parameters, etc. Please adjust the dilution solvent according to the actual situation.

2. The amount of isopropyl alcohol shall not exceed 20% of the total dilution solvent.

3. Please refer to the instructions in the following appendix for the boiling resistance of GA-series primary ink. If the spot color ink is intended to be used for boiling resistant packaging, please consult our technical department.

4. Please use GP-Series Retort Gravure Ink for Plastic Laminated Film if applied for retort packaging (above 100 °C).

5. In general, curing agent is not required when printing on BOPP or PET substrate under the boiling condition of 100 °C/40 min. However, due to the different adhesive types and laminating conditions applied by various manufacturers, customers are requested to make necessary confirmation during application.

6. When printing on NY film, it is recommended to add the GA-07 Curing Agent in the background white ink as a supplement under the boiling condition of 100 °C/40 min, to obtain more stable bond strength. The amount of curing agent added is generally 3-4% of the original ink.

7. The products marked with "Infiltration" shall not be used for NY-base material, boiled products and solvent-free laminated products; otherwise color migration is likely to occur.

8. Please store the product in a cool and ventilated place away from direct sunlight.

Please contact with our technical department if any consultation requested or any abnormal situation encountered with.

Appendix: Boiling Resistance of GA-Series Ink

Color	Model No.	BOPP film or PET film(Boiled at 100℃/40min)	NY film (Boiled at 100℃/40min)	Color	Model No.	BOPP film or PET film(Boiled at 100℃/40min)	NY film (Boiled at 100℃/40min)
Red	GA1002	√	√	Black	GA5002	√	√
	GA1004	√	√		GA5016	√	√
Yellow	GA2002	√	√	Green	GA6050	√	√
	GA2003	√	√	Purple	GA7045	√	√
Transparent yellow	GA2061	√	√	Orange	GA2017	√	×
Blue	GA3001	√	√	Peach	GA1891	√	√
	GA3002	√	√	Gold or silver ink	GH-Series	×	×
White	GA4002	√	√	Varnish	GA8002	√	√
	GA4003	√	√
	GA4015	√	√
	GA4016	√	√

Notes: 1. In the table, "√" indicates applicable and "×" indicates not applicable.

          2. Please consult our technical department for the application performance of other types of ink.
